Camera Data Cable, 850 nm (LS-AC50G-QSFP28-850-MPO)
Model LS-AC50G-QSFP28-850-MPO
Camera Data Cable, 850 nm. Compliant with IEEE 802.3bm for 50G MPO fiber connections QSFP28 optical module: high density, low power and cost-effective
Features
- Compliant with IEEE 802.3bm for 50G MPO fiber connections
- QSFP28 optical module: high density, low power and cost-effective
- All-metal housing improves EMI performance; hot-swappable
- 850 nm center wavelength with MPO interface for connecting MPO fiber equipment on industrial vision sites
Specifications
| Model | LS-AC50G-QSFP28-850-MPO |
|---|---|
| Central wavelength | 850 nm |
| Interface type | QSFP28 |
| Connector type | MPO |
| Transmission speed | 50 Gbps |
| Transmission distance | 100 m |
| Transmit power | -8.4 ~ 2.4 dBm |
| Received power | -10.3 ~ 2.4 dBm |
| Working temperature | 0°C ~ 70°C |
| Certification | RoHS |
| Packaging | Individual package |
| Shipping weight (estimated) | 0.31 kg |
