MEAN WELL LRS-75-48 Industrial Power Supply, 48 V 76.8 W
Model LRS-75-48
MEAN WELL LRS-75-48 Industrial Power Supply, 48 V 76.8 W. The industrial power supply adopts terminal blocks as connectors, and can be used to power the device. Multiple specifications are available.
Features
- The industrial power supply adopts terminal blocks as connectors, and can be used to power the device. Multiple specifications are available.
Specifications
| Model | LRS-75-48 |
|---|---|
| Brand | MEAN WELL |
| End A connector | Terminal block (220 VAC/DC Input) |
| End B connector | Terminal block |
| Applicable scenario | Static |
| Input voltage range | 85 VAC ~ 264 VAC; 120 VDC ~ 373 VDC |
| Input AC current | 1.4 A @ 115 VAC; 0.85 A @ 230 VAC |
| Output power | 76.8 W max |
| Output voltage | 48 V |
| Output current | 0 A ~ 1.6 A |
| Over current protection | > 120% of rated current, hiccup mode |
| Over voltage protection | Overvoltage protection range: ; 55.2 V to 64.8 V; Protected mode: ; Turn off the output voltage, restart and restore. |
| MTBF | 3, 334, 300 h; (Standard: Telcordia SR-332) |
| Working temperature | –30 °C to 70 °C (–22 °F to 158 °F); (For temperatures above 50 °C, the output load decreases by 2% for every degree increase in temperature.) |
| Certification | CE, UL, CCC, EMC, EAC, TUV, UK |
| Packaging | Individual package |
| Shipping weight (estimated) | 0.31 kg |
