MEAN WELL LRS-150F-24 Industrial Power Supply, 24 V 150 W
Model LRS-150F-24
MEAN WELL LRS-150F-24 Industrial Power Supply, 24 V 150 W. The industrial power supply adopts terminal blocks as connectors, and can be used to power the device. Multiple specifications are available.
Features
- The industrial power supply adopts terminal blocks as connectors, and can be used to power the device. Multiple specifications are available.
Specifications
| Model | LRS-150F-24 |
|---|---|
| Brand | MEAN WELL |
| End A connector | Terminal block (220 VAC/DC Input) |
| End B connector | Terminal block |
| Applicable scenario | Static |
| Input voltage range | 85 VAC ~ 264 VAC; 125 VDC ~ 375 VDC |
| Input AC current | 1.7 A @ 115 VAC; 1 A @ 230 VAC |
| Output power | 150 W max |
| Output voltage | 24 V |
| Output current | 0 A ~ 6.25 A |
| Over current protection | > 120% of rated current, hiccup mode |
| Over voltage protection | Overvoltage protection range:; 28.8 V to 33.6 V; Protected mode:; Turn off the output voltage, restart and restore. |
| MTBF | 700, 000 h; (Standard: Telcordia SR-332) |
| Working temperature | –10 °C to 70 °C (14 °F to 158 °F); (For temperatures above 50 °C, the output load decreases by 2.5% for every degree increase in temperature.) |
| Certification | CE, UL, CCC, SIQ |
| Packaging | Individual package |
| Shipping weight (estimated) | 0.31 kg |
