Smart cameras & vision sensors

Hikrobot MV-SC3013XM-12M-WBN SC3000X series vision sensor, 1.3MP, Mono, 12mm focal length

Model MV-SC3013XM-12M-WBNHikrobot

Resolution1216 × 1024
SensorCMOS, global shutter
InterfaceFast Ethernet (100 Mbit/s)
Speed60 fps
Lens mountM12
Mono / colourMono

$1,809.00

Ships in 2-3 weeks

0.37 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Available in the US - comparable cameras:

1.2 MP smart camera, 60 fps, 12 mm lens (LS-SMC-0029)$1,330.00
1.2 MP smart camera, 60 fps, 8 mm lens (LS-SMC-0027)$1,330.00
1.2 MP smart camera, 60 fps, 16 mm lens (LS-SMC-0031)$1,330.00

Ask an engineer Browse Smart cameras & vision sensors

MV-SC3013XM-12M-WBN: resolution 1216 x 1024; sensor type CMOS, global shutter; sensor size 1/1.45"; max. frame rate 60 fps; mono/color Mono.

Hikrobot MV-SC3013XM-12M-WBN SC3000X series vision sensor, 1.3MP, Mono, 12mm focal length. Adopts embedded hardware platform to realize high-speed image processing. Built-in high-precision positioning, measurement and recognition algorithms for counting, defects, existence, positioning and other functions.

Tracked worldwide shippingTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CEKC

Specifications

General

Model	MV-SC3013XM-12M-WBN
Brand	Hikrobot
Vision tool	Measurement: P2P measurement, P2L measurement, contrast measurement, grayscale size, edge width measurement, width measurement, brightness average value, L2L angle, diameter measurement, line angle; Existence: Spot existence, edge existence, contour existence, pattern existence, circle existence, line existence, anomaly judge, existence detection; Count: Spot count, edge count, contour count, pattern count, learning-based count; Recognition: Multi-object count, code recognition, category recognition, classification registration, object registration, OCR, learning-based OCR, character horizontal stripe detection; Logic: Calculator, if module, logic judge, format output, condition judge, character comparison, combination judge; Location: Calibration convert, single point alignment, point rectify, point grasp, scale transformation, fixture; Deep learning: DL classification, DL object detection; Defect detection: Anomaly detection; Industry tools: OCR and defect detection
Solution capacity	Supports importing and exporting project, up to 32 projects can be stored
Lens cap	Polarized + diffuser + full-transparent lens cap
Indicator	360° visual indicator

Optics

Focal length	12 mm

Sensor and imaging

Sensor type	CMOS, global shutter
Pixel size	6.9 μm × 6.9 μm
Sensor size	1/1.45"
Resolution	1216 × 1024
Max. frame rate	60 fps
Gain	0 dB to 15 dB
Exposure time	6 μs to 1 sec
Pixel format	Mono 8
Mono/color	Mono
Aiming system	1 LED

Interfaces and I/O

Communication protocol	RS-232, TCP, UDP, FTP, PROFINET, Modbus, EtherNet/IP, MELSEC/SLMP, FINS, Keyence KV
Data interface	Fast Ethernet (100 Mbit/s)
Digital I/O	12-pin M12 connector provides power and I/O, including opto-isolated input (LINE 0/1/2) × 3, opto-isolated output (LINE 3/4/5) × 3, and RS-232 × 1; Supports triggering device via pressing top trigger button
Client software	SCMVS

Light

Light source	White spot light source. Red/blue/IR point light source is optional

Environment and compliance

Ingress protection	IP67 (under proper installation of waterproof lens cap)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Vibration resistance	Meets standard IEC 60068-2-6:2007.; Device only (without installation bracket): 10 Hz to 55 Hz, 1.5 mm peak-to-peak amplitude, 2 hours per axis (X, Y, Z)
Shock resistance	Meets standard IEC 60068-2-27:2008.; Device only (without installation bracket): 30 g / 11 ms, half-sine wave, 500 shocks per axis (6 directions)
Certification	CE, KC

Electrical

Power supply	24 VDC
Power consumption	Avg. 7 W @ 24 VDC (light source enabled); Max. 22 W @ 24 VDC (light source enabled)

Mechanical

Lens mount	M12-mount, mechanical autofocus supported
Dimension	Straight angle: 80.1 mm × 43 mm × 44.3 mm (3.2" × 1.7" × 1.7"); Right angle: 58.5 mm × 43 mm × 65.4 mm (2.3" × 1.7" × 2.6")
Weight	Approx. 190 g (0.4 lb.)
Shipping weight (estimated)	0.37 kg

Downloads

Features

Frame rate up to 60 fps
Exposure time 6 µs to 1 s
Adopts embedded hardware platform to realize high-speed image processing.
Built-in high-precision positioning, measurement and recognition algorithms for counting, defects, existence, positioning and other functions.
Supports RS-232, TCP, UDP, FTP, Modbus, PROFINET, EtherNet/IP and other communication modes.
Adopts multiple IO interfaces for input and output signals.
Supports viewing the device's status in real time via 360° visual indicator, convenient for debugging and maintenance.
Rotatable cable tail design, suitable for narrow space.
Adopts polarized, diffuser, and full-transparent multiple optical lighting with good environmental adaptability.
IP67 protection without fear of harsh industrial application environments.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer

Engineering data

The MV-SC3013XM-12M-WBN at a glance

The numbers that set this model apart, taken from its own printed specifications.

Resolution1216 × 1024 px

Max. frame rate60 fps

Focal length12 mm

Ingress protectionIP67

Power consumption7 Wavg. at 24 V DC; max. 22 W

ShutterGlobal
