3D sensors

Hikrobot MV-RS-Ultra-L Galvanometer Laser 3D Camera

Model MV-RS-Ultra-LHikrobot

InterfaceGigabit Ethernet (1000 Mbit/s)
TypeStereo / structured light
Near field of view700 mm × 600 mm @ 1300 mm
Typical field of view1000 mm × 900 mm @ 1700 mm

Price on request

Ships in 2-3 weeks

3.39 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Ask an engineer Browse 3D sensors

MV-RS-Ultra-L: measurement range (MR) 800 mm, clearance distance (CD) 1300 mm, repeatability (z-axis)* 0.08 mm @ 1800 mm, near field of view 700 mm x 600 mm @ 1300 mm.

Hikrobot MV-RS-Ultra-L Galvanometer Laser 3D Camera. Customized optical system provides high-quality image. Supports high-uniformity laser module to provide a more detailed point cloud.

Tracked worldwide shippingTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)RoHSCE

Specifications

General

Model	MV-RS-Ultra-L
Brand	Hikrobot
Clearance distance (CD)	1300 mm
Measurement range (MR)	800 mm
Repeatability (Z-axis)*	0.08 mm @ 1800 mm
VDI/VDE accuracy*	0.15 mm @ 1800 mm
Data acquisition time	0.4 s to 0.9 s
Data type	Original image (mono and color images), depth image, RGB-D image
Laser safety class	Class 2

Optics

Near field of view	700 mm × 600 mm @ 1300 mm
Typical field of view	1000 mm × 900 mm @ 1700 mm
Far field of view	1200 mm × 1100 mm @ 2100 mm

Sensor and imaging

Resolution	RGB: 4000 × 3000; Depth: 2448 × 2048

Interfaces and I/O

Data interface	Gigabit Ethernet (1000 Mbit/s)
Digital I/O	12-pin M12 interface provides power and I/O, including opto-isolated input × 3 (Line 0/3/6), opto-isolated output × 3 (Line 1/4/7)
Client software	RobotPilot, HiViewer

Light

Wavelength	638 nm

Environment and compliance

Ingress protection	IP65
Temperature	Working temperature: 0 °C to 45 °C (32 °F to 113 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity	20% RH to 85% RH (no condensation)
Certification	RoHS, CE

Computing

Operating system	32/64-bit Windows 7/10, 64-bit Windows 11

Electrical

Image output delay	1.0 s to 1.7 s
Power supply	24 VDC
Power consumption	Typ. 15 W @ 24 VDC

Mechanical

Dimension	525.7 mm × 81.8 mm × 107.4 mm (20.7" × 3.2" × 4.2")
Weight	Approx. 2.35 kg (5.2 lb.)
Shipping weight (estimated)	3.39 kg

Downloads

Features

RoHS and CE compliant
Customized optical system provides high-quality image.
Supports high-uniformity laser module to provide a more detailed point cloud.
Supports multi-core parallel processing with high precision and high image acquisition rate.
Supports alignment between depth images and RGB images, convenient for secondary development.
Adopts high-strength carbon fiber design with high stability.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer

Other models in the RoboScan Ultra Series 3D Camera series

See all 4 models

Model	Near field of view	Typical field of view	Price	Availability	Link
MV-RS-Ultra-LThis model	700 mm × 600 mm @ 1300 mm	1000 mm × 900 mm @ 1700 mm	On request	Ships in 2-3 weeks	Compare
MV-RS-Ultra-S	240 mm × 260 mm @ 500 mm	320 mm × 320 mm @ 600 mm	On request	Ships in 2-3 weeks	CompareView
MV-RS-Ultra-XL	1300 mm × 1100 mm @ 1500 mm	2200 mm × 2000 mm @ 2500 mm	On request	Ships in 2-3 weeks	CompareView
MV-RS-Ultra-M	540 mm × 530 mm @ 700 mm	890 mm × 760 mm @ 1000 mm	On request	Ships in 2-3 weeks	CompareView
