Hikrobot ICRS016-110M 1.6 MP industrial code reader

Fixed code readers

Hikrobot MV-ID3168XM 1.6 MP industrial code reader

Model MV-ID3168XMHikrobot

Resolution1408 × 1024
SensorCMOS, global shutter
InterfaceFast Ethernet(100 Mbit/s)
Speed60 fps
Lens mountM12
Mono / colourMono

$1,979.00

Ships in 2-3 weeks

0.37 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Available in the US - comparable cameras:

1408 x 1024 fixed code reader, 60 fps, 110 yards/s, autofocus, 8 mm lens (LS-CRD-0011)$1,165.00
1408 x 1024 fixed code reader, 60 fps, 45 yards/s, 6.7 mm lens (LS-CRD-0010)$500.00
1408 x 1024 fixed code reader, 60 fps, 84 yards/s, autofocus, 6 mm lens (LS-CRD-0008)$735.00

Hikrobot MV-ID3168XM 1.6 MP industrial code reader. Built-in deep-learning decoding algorithm: robust under a wide range of difficult conditions Carefully selected sensor for high-speed capture of high-quality images

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-ID3168XM
Brand	Hikrobot
Lens cap	Polarized + diffuser + full-transparent lens cap
Indicator	Device body indicator, reading result indicator

Optics

Focal length	8 mm

Sensor and imaging

Symbologies	1D code: Code 39, Code 93, Code 128, CodaBar, EAN8, EAN13, ITF25, ITF14, MATRIX25, UPCA, UPCE, MSI, CODE11, INDUSTRIAL25, CHINAPOST, PHARMACODE; 2D code: QR Code, Data Matrix, Micro QR; Stacked code: PDF417
Max. frame rate	60 fps
Max. reading speed	110 codes/s
Sensor type	CMOS, global shutter
Pixel size	3.45 μm × 3.45 μm
Sensor size	1/2.9”
Resolution	1408 × 1024
Exposure time	6 μs ~ 30000 μs
Gain	0 ~ 24 dB
Mono/color	Mono
Aiming system	Orange LED

Interfaces and I/O

Communication protocol	SmartSDK, TCP Client, Serial, FTP, TCP Server, Profinet, Melsec/SLMP, EthernetIp, Modbus, FINS, UDP
Data interface	Fast Ethernet(100 Mbit/s)
Digital I/O	12-pin M12 connector provides power and I/O: 3 opto-isolated inputs (pins 0/1/2 input), 3 opto-isolated outputs (pins 3/4/5), 1 RS-232 port; Triggering via top button supported
Client software	IDMVS

Light

Light source	Red spot light and white diffuse light, Spot light: white/blue/IR optional

Environment and compliance

Ingress protection	IP67 (under proper installation of waterproof lens cap)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, RoHS, KC

Electrical

Power supply	24 VDC
Max. power consumption	6.2 W @ 24 VDC (built-in light on)

Mechanical

Lens mount	M12-mount, mechanical focus
Dimension	Straight: 80.1 mm × 43 mm × 44.3 mm; Right-angle: 58.5 mm × 43 mm × 65.4 mm
Weight	Approx. 195 g (0.4 lb.)
Shipping weight (estimated)	0.37 kg

Downloads

Datasheet (PDF, Chinese)MV-ID3168XM · 916 KB

Features

Built-in deep-learning decoding algorithm: robust under a wide range of difficult conditions
Carefully selected sensor for high-speed capture of high-quality images
Liquid-lens models combine with ToF for fast image setup and real-time focusing
Extremely easy to use: one-click auto-tuning
Top and side status indicators plus projected light: code-reading status visible from every side
Rotatable tail cable design adapts flexibly to tight spaces
Three-way polarized, diffuse and clear illumination for outstanding environmental adaptability
Rich I/O interface for multiple input and output signals
IP67 protection for harsh industrial environments
