Manual X / Y / Z axis displacement slide stages, travel ±10mm (LS-Z4040)
Model LS-Z4040
- MaterialAluminum alloy
- Travel±10mm
- Load29.4N(3kgf)
- TypeManual slide stages
$159.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.45 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Manual X / Y / Z axis displacement slide stages. Camera stand brackets and manual / motorized slide plate accessories for automation and vision set-ups. At a glance: travel ±10mm; load 29.4N(3kgf); table size 40 x 40 mm.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-Z4040 |
|---|---|
| Axis | Z |
| Min. scale | 0.01mm |
| Precision | 0.03mm |
| Parallelism | 0.03mm |
| Movement | Z axis |
| Drive | Gear rack, manual |
| Movement parallelism | <0.3/24 |
Mechanical
| Travel | ±10mm |
|---|---|
| Load | 29.4N(3kgf) |
| Material | Aluminum alloy |
| Weight | 0.25kg |
| Table size | 40 x 40 mm |
| Shipping weight (estimated) | 0.45 kg |
