Shadowless lights
48 mm OD Ring Shadowless Light (LS-SR-48)
Model LS-SR-48
- ColourRed, Green, Blue, White
- Voltage24 V
- Power3.8 W
- Power R2.2 W
$119.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.2 kg shipping weight
Volume pricing, Net 30 or a formal quote?
48 mm OD Ring Shadowless Light. Ring shadowless light that eliminates reflective interference and provides high-brightness, high-uniformity diffuse illumination.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SR-48 |
|---|---|
| OD x ID x H (mm) | 48x10x18.5 |
Interfaces and I/O
| Cable lead (mm, per drawings) | 500 |
|---|
Light
| Colours | Red, Green, Blue, White |
|---|
Electrical
| Voltage (V) | 24 |
|---|---|
| Power R (W) | 2.2 |
| Power W/B/G (W) | 3.8 |
Mechanical
| Shipping weight (estimated) | 0.20 kg |
|---|
Mounting and drawing data
drawing: 4-M3 depth 4 on dia 38
