300 x 20 mm Water-Cooled IR Line Special Light (LS-SPC-0100)
Model LS-SPC-0100
- ColourInfrared
- Emitting area300x20 mm
- Size530x44x62 mm
- Voltage48 V
Ships in 2-3 weeks
1.35 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
300 x 20 mm Water-Cooled IR Line Special Light. Water-cooled infrared line scan light with closely arranged high-power IR LEDs, for inspecting silicon wafers for cracks and defects. Narrow-band emission reduces external interference and a temperature control switch protects against cooling problems.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SPC-0100 |
|---|---|
| Cooling | Water (dia. 8 pipe connectors) |
Light
| Emitting area (mm) | 300x20 |
|---|---|
| Colours | Infrared |
Electrical
| Voltage (V) | 48 |
|---|---|
| Power IR (W) | 200 |
Mechanical
| Outer size L x W x H (mm) | 530x44x62 |
|---|---|
| Shipping weight (estimated) | 1.35 kg |
Mounting and drawing data
Generic drawing: emitting length A, body length A + 30, emitting width 20, width 44, height 62 (+27 for fittings), 31 mm end profile, dia. 8 water pipe connectors, 2 x M4 nut mounting slot. The specification table gives a length of 530 mm (the drawing rule gives 330 mm for A = 300); please confirm with us before designing in.
