Machine vision lenses
25 mm, 1.1", 12 MP, C-mount Macro Lens (LS-SMC2528-12M)
Model LS-SMC2528-12M
- Focal length25 mm
- Magnification0.1x-0.4x
- MountC-mount
- Sensor1.1"
- Working distance65-206 mm
- ApertureF2.8 Manual Iris
$319.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.39 kg shipping weight
Volume pricing, Net 30 or a formal quote?
25 mm, 1.1", 12 MP, C-mount Macro Lens. Industrial macro lenses for measuring small objects at short distances where space is restricted; they solve many tasks that previously needed ultra-long focal length or even telecentric lenses. Variable magnification, variable working distance and an adjustable aperture make them flexible to use. At a glance: magnification 0.1x-0.4x; working distance 65-206 mm; focal length 25 mm; format 1.1"; resolution 12 Megapixel.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SMC2528-12M |
|---|---|
| Format | 1.1" |
| Flange back | 17.526 mm |
| Object to image distance (O/I) | 126-314.1 mm |
| Angle of view (1.1", HxV) | 140 x 105 deg |
Optics
| Focal length | 25 mm |
|---|---|
| Aperture | F2.8 Manual Iris |
| Working distance | 65-206 mm |
| Magnification | 0.1x-0.4x |
| Distortion | <0.07% |
| Field of view (1.1", HxV) | 140 x 105 mm at 0.1x |
| F-number range | F2.8-16 (±10%) |
| Filter thread | M27.5 x P0.5-6H |
| M.O.D. | 0.065 m |
Sensor and imaging
| Resolution | 12 Megapixel |
|---|
Environment and compliance
| Storage temperature | -20 to +60 °C |
|---|
Mechanical
| Size | dia. 32 x 39.7 mm |
|---|---|
| Mount | C |
| Weight | 210 g |
| Shipping weight (estimated) | 0.39 kg |
Other models in the Macro lenses series
See all 6 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-SMC1628-12M | 16 mm, 1.1", 12 MP, C-mount | $309.00 | 3 in stock | View |
| LS-SMC3528-12M | 35 mm, 1.1", 12 MP, C-mount | $339.00 | 3 in stock | View |
| LS-SMC5028-12M | 50 mm, 1.1", 12 MP, C-mount | $359.00 | 4 in stock | View |
| LS-SMC7538-12M | 75 mm, 1.1", 12 MP, C-mount | $389.00 | 5 in stock | View |
| LS-S12MC9028-20M | 90 mm, 1.2", 20 MP, C-mount | $589.00 | 4 in stock | View |
