Representative photo of this series
Shadowless lights
Square shadowless light, recommended working distance 10~100 mm (LS-SDL-0143)
Model LS-SDL-0143
- ColourRed, Green, Blue, White
- Voltage24 V
- Min. size156 mm x 113 mm
- Max. size200 mm x 180 mm
$499.00
Ships in 2-3 weeks
0.75 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
The flexible PCB is fixed with 90 degrees LEDs; high uniformity and high density LEDs provide diffused, soft light; best suited for square shape objects and other different objects. It mainly applied avoid reflation or flare.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SDL-0143 |
|---|---|
| FOV | 1~150 mm |
| Note | UV & IR light can be customized as required. |
Optics
| Recommended working distance | 10~100 mm |
|---|
Interfaces and I/O
| Cable length | 500 mm |
|---|---|
| Extension cable options | PVC extension cable (high flexibility, bending and high-temperature resistant, for use inside equipment); high-flexibility extension cable (harder, more abrasion resistant, for drag-chain production lines) |
Light
| Colour temperature of white | 6600 K |
|---|
Environment and compliance
| Operating temperature | 0-50 °C |
|---|---|
| Operating humidity | 20-85% (non-condensing) |
| Lifespan | 50000 h (to 50% of factory default luminance) |
Electrical
| Voltage | 24 V |
|---|---|
| Adapted controllers | Strobe controller, analog controller, digital controller |
| Power (R) | 13.5W |
| Power (G/B/W) | 20.2W |
Mechanical
| Min. size | 156 mm x 113 mm |
|---|---|
| Max. size | 200 mm x 180 mm |
| Weight | 481 g |
Other models in the Square shadowless light (LS-SDL-S25) series
See all 6 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-SDL-0142 | Red, Green, Blue, White · 110 x 75 mm | $609.00 | Ships in 2-3 weeks | View |
| LS-SDL-0145 | Red, Blue, Green, White · 125 x 125 mm | $699.00 | Ships in 2-3 weeks | View |
| LS-SDL-0144 | Red, Green, Blue, White · 152 x 76 mm | $839.00 | Ships in 2-3 weeks | View |
| LS-SDL-0146 | Red, Green, Blue, White · 232 x 140 mm | $1,359.00 | Ships in 2-3 weeks | View |
| LS-SDL-0147 | Red, Blue, Green, White · 302 x 160 mm | $1,929.00 | Ships in 2-3 weeks | View |
