Arch shadowless light (LS-SDL-S04)
  • Arch shadowless light (LS-SDL-S04)
  • LS-SDL-0020 dimensions (mm)

Representative photo of this series. Colour shown for illustration; the actual product may differ

Shadowless lights

125 x 70 mm Arch shadowless light (LS-SDL-0020)

Model LS-SDL-0020

  • ColourRed, Green, Blue, White
  • Emitting area125 x 70 mm
  • SizeL139xW112xH62(mm)
  • Voltage24 V
  • Power15.4W/17.3W
$469.00

Ships in 2-3 weeks

0.9 kg shipping weight

Color

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

125 x 70 mm Arch shadowless light (LS-SDL-0020)LS-SDL-0020

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

The shadowless vault light, which high-intensity and high-uniform LEDs mounted on it, is pretty suitable for the inspection of reflective objects. The middle hole can be customized according to customers’ needs in order to be compatible with the plane array camera.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-SDL-0020
FOV1~200m (as printed)
NoteUV & IR light can be customized as required.
Viewport (camera hole)dia. 45

Optics

Recommended working distance5~50 mm

Interfaces and I/O

Cable length500 mm
Extension cable optionsPVC extension cable (high flexibility, bending and high-temperature resistant, for use inside equipment); high-flexibility extension cable (harder, more abrasion resistant, for drag-chain production lines)
Cable polarity1: +, 2: NC, 3: -

Light

Colour temperature of white6600 K
Emitting surface (mm)125 x 70
LED colourW(white)

Environment and compliance

Operating temperature0-50 °C
Operating humidity20-85% (non-condensing)
Lifespan50000 h (to 50% of factory default luminance)

Electrical

Voltage24 V
Adapted controllersStrobe controller, analog controller, digital controller
Power (R)5.8W
Power (G/B/W)8.6W
Power15.4W/17.3W
Input voltageDC 24V (max)

Mechanical

Min. size102 mm x 128 mm
Max. size350 mm x 175 mm
Weight619 g
DimensionL139xW112xH62(mm)
Mounting holes2×4-M4 depth 4
