Representative photo of this series
Shadowless lights
Square shadowless light, 173 x 165 x 42 mm (LS-RIH125125)
Model LS-RIH125125
- ColourRed, Blue, Green, White
- Emitting area125 x 125 mm
- SizeL173xW165xH42(mm)
- Voltage24 V
- Power12.3W/15.2W
$439.00
In stock - ships the same business day (4 available, order by 2 PM ET)
1.0 kg shipping weight
Volume pricing, Net 30 or a formal quote?
The flexible PCB is fixed with 90 degrees LEDs; high uniformity and high density LEDs provide diffused, soft light; best suited for square shape objects and other different objects. It mainly applied avoid reflation or flare.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-RIH125125 |
|---|---|
| FOV | 1~150 mm |
| Note | UV & IR light can be customized as required. |
Optics
| Recommended working distance | 10~100 mm |
|---|
Interfaces and I/O
| Cable length | 500 mm |
|---|---|
| Extension cable options | PVC extension cable (high flexibility, bending and high-temperature resistant, for use inside equipment); high-flexibility extension cable (harder, more abrasion resistant, for drag-chain production lines) |
| Cable polarity | 1: +, 2: NC, 3: - |
Light
| Colour temperature of white | 6600 K |
|---|---|
| LED colour | R(red)/W(white) |
| Emitting surface (mm) | 125 x 125 |
Environment and compliance
| Operating temperature | 0-50 °C |
|---|---|
| Operating humidity | 20-85% (non-condensing) |
| Lifespan | 50000 h (to 50% of factory default luminance) |
Electrical
| Voltage | 24 V |
|---|---|
| Adapted controllers | Strobe controller, analog controller, digital controller |
| Power | 12.3W/15.2W |
| Input voltage | DC 24V (max) |
Mechanical
| Min. size | 156 mm x 113 mm |
|---|---|
| Max. size | 200 mm x 180 mm |
| Dimension | L173xW165xH42(mm) |
| Mounting holes | 8-M4 depth 4 |
| Shipping weight | 1.00 kg |
Other models in the Square shadowless light (RIH) series
See all 6 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-RIH13294 | Red, Green, Blue, White · 24 V | $299.00 | 12 in stock | View |
| LS-RIH11075 | Red, Green, Blue, White · 110 x 75 mm | $379.00 | 10 in stock | View |
| LS-RIH15075 | Red, Green, Blue, White · 152 x 76 mm | $539.00 | 13 in stock | View |
| LS-RIH232140 | Red, Green, Blue, White · 232 x 140 mm | $909.00 | 17 in stock | View |
| LS-RIH302156 | Red, Blue, Green, White · 302 x 160 mm | $1,299.00 | 14 in stock | View |
