Constant current controller (ACC) for spot lights
  • Constant current controller (ACC) for spot lights

Light controllers

2-Channel Constant-Current LED Light Controller, 5V (LS-MACC515-2H)

Model LS-MACC515-2H

  • Output5V
  • InputDC 9-26V
  • Total output1.6A
  • Channels2 channels
$219.00

In stock - ships the same business day (5 available, order by 2 PM ET)

0.3 kg shipping weight

Volume pricing, Net 30 or a formal quote?

2-Channel Constant-Current LED Light Controller, 5V. Constant current controller that powers spot lights; a single channel can pass 680mA current max.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-MACC515-2H
Control methodknob
DimmingStepless knob per channel

Interfaces and I/O

Light connector wiringLight "+", Light "-", NC

Electrical

Output CH2CH
Input voltageDC 9-26V
Output voltage5V
Single CH current0.8A
Total output current1.6A
External trigger voltageX

Mechanical

Shipping weight (estimated)0.30 kg

Mounting and drawing data

Per-channel DC input port CH1 (9-26V), CH2 (9-26V); drawing W62 x H89 x D55 (body 45); base mounting clip 68 x 35

Other models in the Constant current controller (ACC) for spot lights series

See the category
ModelSize / key dataPriceAvailabilityLink
LS-ACC515-4H 4 ch, 5V $289.00 4 in stock View
