Line scan lenses
116 mm, 0.75x Line Scan Lens (LS-LSL-0243)
Model LS-LSL-0243
- Focal length116 mm
- Magnification0.7-0.85x
- MountM42
- SensorLarge format
- Working distance206-235 mm
$3,209.00
Ships in 2-3 weeks
0.94 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
116 mm, 0.75x Line Scan Lens. Line scan lens selection table: focal length, maximum image circle, center magnification / working distance, FOV per camera type and mount options. At a glance: center magnification 0.75x; center working distance 224 mm; focal length 116 mm; sensor class 16K 5 um; mount options M42, M58, M72, M90, M95.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LSL-0243 |
|---|---|
| Center conjugate distance (I.O) | 452 mm |
| FOV with 16k 5 um camera | 94-114 mm |
| FOV with 16k 3.5 um camera | 66-80 mm |
| FOV with 8k 7 um camera | 66-80 mm |
| Conjugate distance range (I.O) | 445-457 mm |
Optics
| Focal length | 116 mm |
|---|---|
| Max image circle | dia. 82 mm |
| Center magnification | 0.75x |
| Center working distance | 224 mm |
| Magnification range | 0.7-0.85x |
| Working distance range | 206-235 mm |
Sensor and imaging
| Sensor class | 16K 5 um |
|---|
Mechanical
| Mount options | M42, M58, M72, M90, M95 |
|---|---|
| Shipping weight (estimated) | 0.94 kg |
Photo shows a representative model of this series; see the specifications for this model.
