Representative photo of this series
Line scan lights
120 x 85 mm Tunnel line scan light, fan cooled (LS-LSC-0680)
Model LS-LSC-0680
- ColourRed, Green, Blue, White
- Emitting area120 x 85 mm
- Voltage24 V DC (LS-LSC-0686: 48 V)
- Power135 W
$549.00
Ships in 2-3 weeks
2.45 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Tunnel line scan light with good parallelism and high luminance in a compact, stable and durable structure. Used for inspecting workpieces that need a uniform surface, together with a line scan camera.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LSC-0680 |
|---|---|
| Cooling | Fan cooling |
| UV / IR | UV & IR light can be customized as required |
| FOV | 1-800 mm |
Optics
| Recommended working distance | 5-200 mm |
|---|
Interfaces and I/O
| Cable | 500 mm (LS-LSC-0686: 1000 mm) |
|---|---|
| Extension cable options | PVC extension cable (flexible, bend and heat resistant, for use inside equipment); high-flexibility extension cable (harder and more abrasion resistant than PVC, for drag-chain production lines) |
Light
| Peak wavelength / colour temperature | Red 620-630 nm, Green 525-530 nm, Blue 465-470 nm, White 6600 K (colour temperature) |
|---|---|
| Emitting length range (mm) | 120-1000 |
| Emitting length (mm) | 120 |
| Emitting surface (mm) | 120 x 85 |
Environment and compliance
| Operating environment | Temperature 0-50 °C, humidity 20-85% (non-condensing) |
|---|---|
| Lifespan | 50000 h (to 50% of factory-default luminance) |
Electrical
| Adapted controller | High power constant voltage controller LS-CTL-S03; high power constant current controller LS-CTL-S03 (as printed) |
|---|---|
| Voltage | 24 V DC (LS-LSC-0686: 48 V) |
| Voltage (V) | 24 |
| Power (W) | 135 |
Mechanical
| Height (mm) | 84 (88.7-89 overall) |
|---|---|
| Weight (g) | 1994 |
Other models in the Tunnel line scan light, fan cooled (LS-LSC-S67) series
See all 8 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-LSC-0681 | 200 x 85 mm | $779.00 | Ships in 2-3 weeks | View |
| LS-LSC-0687 | 238 x 75 mm | $889.00 | Ships in 2-3 weeks | View |
| LS-LSC-0682 | 260 x 85 mm | $959.00 | Ships in 2-3 weeks | View |
| LS-LSC-0683 | 350 x 85 mm | $1,209.00 | Ships in 2-3 weeks | View |
| LS-LSC-0684 | 420 x 85 mm | $1,419.00 | Ships in 2-3 weeks | View |
| LS-LSC-0685 | 500 x 85 mm | $1,649.00 | Ships in 2-3 weeks | View |
| LS-LSC-0686 | 1000 x 85 mm | $3,059.00 | Ships in 2-3 weeks | View |
