Polarized high-power line scan light (series view)
  • Polarized high-power line scan light (series view)
  • Polarized high-power line scan light (series view)
  • 2200 x 17 mm polarized high-power line scan light

Rendered illustration: the actual product may differ in appearance.

Line scan lights

2200 x 17 mm polarized high-power line scan light (LS-LSC-0466)

Model LS-LSC-0466

  • ColourRed, Blue, White, Green, Infrared, UV
  • Emitting area2200 x 17 mm
  • Size2270 × 58 × 90 mm
  • Voltage48 VDC
  • Power778 w
$3,575.00

Ships in 3-4 weeks

5.0 kg shipping weight

Color

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

2200 x 17 mm polarized high-power line scan light (LS-LSC-0466)LS-LSC-0466

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Polarized high-power line scan light for line-scan cameras on moving webs and conveyors. Emitting area 2200 x 17 mm; 48 V DC supply; available in red, blue, white, green, infrared (850 / 940 nm), UV.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-LSC-0466
Service lifeWhite:30,000hrs, Red: 60,000hrs (Depends on the operating environment, not a gurantee)
Pin assignment1: (+), 2: NC, 3: (-)

Interfaces and I/O

ConnectorZHQCN-19M-6H
Cable length0 mm

Light

Emitting area (mm)2200 x 17
Wavelength1:(Light source +), 2: (Light source -), 3:(Fan +), 4:(Fan -), 5:(R +), 6:(R -)

Environment and compliance

Operating environmentTemperature: 0~40 °C Humidity:20% to 85% RH (with no condensation)

Electrical

Supply voltage48 VDC
Power778 w

Mechanical

Housing materialAluminum alloy, Resin
Dimensions (mm)2270 × 58 × 90 mm
Shipping weight5.00 kg

Other models in the Polarized high-power line scan lights (LS-LSC-S49) series

See all 17 models
ModelSize / key dataPriceAvailabilityLink
LS-LSC-0451 100 x 17 mm from $500.00 Ships in 3-4 weeks View
LS-LSC-0452 168 x 17 mm from $570.00 Ships in 3-4 weeks View
LS-LSC-0453 200 x 17 mm from $570.00 Ships in 3-4 weeks View
LS-LSC-0454 300 x 17 mm from $715.00 Ships in 3-4 weeks View
LS-LSC-0455 400 x 17 mm from $858.00 Ships in 3-4 weeks View
LS-LSC-0457 600 x 17 mm from $890.00 Ships in 3-4 weeks View
LS-LSC-0456 500 x 17 mm from $1,000.00 Ships in 3-4 weeks View
LS-LSC-0458 650 x 17 mm from $1,144.00 Ships in 3-4 weeks View
LS-LSC-0459 700 x 17 mm from $1,358.00 Ships in 3-4 weeks View
LS-LSC-0460 800 x 17 mm from $1,358.00 Ships in 3-4 weeks View
LS-LSC-0461 900 x 17 mm from $1,500.00 Ships in 3-4 weeks View
LS-LSC-0462 1000 x 17 mm from $1,715.00 Ships in 3-4 weeks View
LS-LSC-0463 1100 x 17 mm from $1,859.00 Ships in 3-4 weeks View
LS-LSC-0464 1200 x 17 mm from $2,145.00 Ships in 3-4 weeks View
LS-LSC-0465 1800 x 17 mm from $2,838.00 Ships in 3-4 weeks View
LS-LSC-0467 3400 x 17 mm from $4,538.00 Ships in 3-4 weeks View
