Rendered illustration: the actual product may differ in appearance.
Line scan lights
305 x 10 mm multi-angle line scan light (LS-LSC-0430)
Model LS-LSC-0430
- Emitting area305 x 10 mm
- Size328 × 300 × 150 mm
- Voltage48 VDC
- Power241.92 w
$200.00
Ships in 3-4 weeks
2.0 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Multi-angle line scan light for line-scan cameras on moving webs and conveyors. Emitting area 305 x 10 mm; 48 V DC supply.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LSC-0430 |
|---|---|
| Service life | White:30,000hrs, Red: 60,000hrs (Depends on the operating environment, not a gurantee) |
Interfaces and I/O
| Cable length | Standard length 485±15 mm, optional 1/2/3 meter long wire |
|---|
Light
| Emitting area (mm) | 305 x 10 |
|---|---|
| Wavelength | Red: 620-630 nm; Blue: 465-475 nm; Green: 515-530 nm; White: 6000-10000K(ColorTemperature) |
Environment and compliance
| Operating environment | Temperature: 0~40 °C Humidity:20% to 85% RH (with no condensation) |
|---|
Electrical
| Supply voltage | 48 VDC |
|---|---|
| Power | 241.92 w |
Mechanical
| Line length | Standard length 485±15 mm, optional 1/2/3 meter long wire |
|---|---|
| Dimensions (mm) | 328 × 300 × 150 mm |
| Housing material | Aluminum alloy, Resin |
| Shipping weight | 2.00 kg |
Other models in the Multi-angle line scan lights (LS-LSC-S47) series
See the category| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-LSC-0429 | 300 x 6 mm | $200.00 | Ships in 3-4 weeks | View |
