Line scan lights
340 mm Mini Line Scan Light (LS-LSC-0370)
Model LS-LSC-0370
- ColourRed, Green, Blue, White
- Emitting area340x10 mm
- Size350x21x34 mm
- Voltage24 V
$699.00
Ships in 2-3 weeks
0.5 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
340 mm Mini Line Scan Light. Compact line scan light (printed as 'Mine Line Scan Light') whose high-power LEDs and condenser structure give high brightness. Its small size suits installations with limited room.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LSC-0370 |
|---|---|
| Outer cross-section WxH | 21x34 mm |
| Lead | 500 mm (drawings) |
Light
| Emitting area (mm) | 340x10 |
|---|---|
| Colours | Red, Green, Blue, White |
| Emitting width | 10 mm (emitting face 10.6 on drawings) |
Electrical
| Voltage (V) | 24 |
|---|---|
| Power R (W) | 15 |
| Power G/B/W (W) | 20 |
Mechanical
| Outer size L x W x H (mm) | 350x21x34 |
|---|---|
| Mounting | Φ3.5 mounting holes on 37.5 mm pitch (100 mm pitch on LS-LSC-0377), 3.7 from base |
| Shipping weight (estimated) | 0.50 kg |
Photo shows a representative model of this series; see the specifications for this model.
Other models in the Mini line scan light (LS-LSC-S41) series
See all 17 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-LSC-0361 | 60 mm | $209.00 | Ships in 2-3 weeks | View |
| LS-LSC-0362 | 100 mm | $279.00 | Ships in 2-3 weeks | View |
| LS-LSC-0363 | 120 mm | $319.00 | Ships in 2-3 weeks | View |
| LS-LSC-0364 | 150 mm | $379.00 | Ships in 2-3 weeks | View |
| LS-LSC-0365 | 200 mm | $469.00 | Ships in 2-3 weeks | View |
| LS-LSC-0366 | 225 mm | $509.00 | Ships in 2-3 weeks | View |
| LS-LSC-0367 | 234 mm | $519.00 | Ships in 2-3 weeks | View |
| LS-LSC-0368 | 250 mm | $549.00 | Ships in 2-3 weeks | View |
| LS-LSC-0369 | 300 mm | $629.00 | Ships in 2-3 weeks | View |
| LS-LSC-0371 | 350 mm | $709.00 | Ships in 2-3 weeks | View |
| LS-LSC-0372 | 400 mm | $789.00 | Ships in 2-3 weeks | View |
| LS-LSC-0373 | 500 mm | $949.00 | Ships in 2-3 weeks | View |
| LS-LSC-0374 | 520 mm | $979.00 | Ships in 2-3 weeks | View |
| LS-LSC-0375 | 600 mm | $1,109.00 | Ships in 2-3 weeks | View |
| LS-LSC-0376 | 660 mm | $1,209.00 | Ships in 2-3 weeks | View |
| LS-LSC-0377 | 1100 mm | $1,909.00 | Ships in 2-3 weeks | View |
