700 mm Coaxial Line Scan Light (LS-LSC-0318)

Model LS-LSC-0318

ColourRed, Green, Blue, White
Emitting area700x20 mm
Size730x50x137.3 mm
Voltage48 V

$2,889.00

Ships in 2-3 weeks

3.05 kg shipping weight

Color Red Green Blue White

Volume pricing, Net 30 terms or a formal quote for purchasing?

700 mm Coaxial Line Scan Light. High-speed, large-format, high-brightness coaxial line illumination with a high-efficiency optical structure. Highly directional light reduces divergence and suits both glossy and matte workpieces.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-LSC-0318

Light

Emitting area (mm)	700x20
Colours	Red, Green, Blue, White
Emitting width	20 mm

Electrical

Voltage (V)	48
Power R (W)	180
Power G/B/W (W)	210

Mechanical

Outer size L x W x H (mm)	730x50x137.3
Outer width	50 mm
Mounting	2X4-M4, 10 deep on end face (holes 28 apart)
Shipping weight (estimated)	3.05 kg

Mounting and drawing data

Height 137.3 mm per the specification table (the drawing and the shorter lengths show 134.3 mm).
