Line scan lenses
4K line scan lens, 20 mm, M42×P1-mount (LS-LS2003C)
Model LS-LS2003C
- Focal length20 mm
- MountV-mount
- SensorAPS-C
- Working distance557.4 mm
- ApertureF4.5-C
$1,019.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.94 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Line scan lenses designed for compact line scan cameras, with standard EFL and magnification options from 0.02x-0.33x; V-mount as standard, adaptable to various camera mounts; applied to printing and packaging inspection.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LS2003C |
|---|---|
| Line scan format | 4K 7µ |
| EFL | 20mm |
| F/NO | 4.5-C |
| Conjugate distance | 619.1 |
| Flange distance | 12 |
Optics
| Max image size | dia. 30 |
|---|---|
| Distortion | <0.01% |
| Standard magnification | 0.0358X |
| Image size (dia.) | dia. 30 |
| Optical distortion | 0.2% |
| Working distance | 557.4 |
| Focal length (mm) | 20 |
| Aperture | F4.5-C |
Sensor and imaging
| Central resolution | 160lp/mm |
|---|---|
| Sensor format | dia. 30 mm image circle |
Mechanical
| Mount | V-Mount |
|---|---|
| Shipping weight | 0.94 kg |
Other models in the 4K line scan lens series
See all 4 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-LS2801A | 29 mm, V-Mount | $1,049.00 | 2 in stock | View |
| LS-LS3508A | 35 mm, V-Mount | $1,069.00 | 3 in stock | View |
| LS-LS4010A | 40 mm, V-Mount | $1,079.00 | 5 in stock | View |
