Analog constant-voltage light controller, 120W, 4 channels, Up to 72 W per channel, SMR-03V-BC connector, With bidirectional trigger, Serial communication. (LS-LEVS-120-4-SY)
  • Analog constant-voltage light controller, 120W, 4 channels, Up to 72 W per channel, SMR-03V-BC connector, With bidirectional trigger, Serial communication. (LS-LEVS-120-4-SY)
  • LS-LEVS-120-4-SY dimensions (mm)

Light controllers

Analog constant-voltage light controller, 120W, 4 channels, Up to 72 W per channel, SMR-03V-BC connector (LS-LEVS-120-4-SY)

Model LS-LEVS-120-4-SY

  • Output24 VDC
  • Input100 ~ 240 VAC, 50/60 Hz
  • ControlNot supported
  • Channels4 channels
$239.00
Quote

Quoted price: add to quote for lead time and volume pricing.

End of life soon: the maker is phasing this model out, so stock is limited. Ask us for availability or the successor model.

Ships in 2-3 weeks

1.08 kg shipping weight

Collect parts in your quote list; we reply with price, lead time and volume pricing.

Analog constant-voltage light controller, 120W, 4 channels, Up to 72 W per channel, SMR-03V-BC connector, With bidirectional trigger, Serial communication. Light brightness set manually or by external trigger Up to 17 A output current per channel

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-LEVS-120-4-SY
Lighting modeAnalog
PWM frequencyNot supported
Dimming modePanel knob
Lighting response time<1 ms
Cooling modeForced cooling (built-in fan)

Interfaces and I/O

Communication protocolNot supported
Applicable productContinuous panel light, Continuous line light
Power supply interfaceAC socket
Console interfaceNot supported
Digital I/O4 inputs, 1 internal power output
Lighting output connectorSMR-03V-BC

Light

Brightness levelStepless dimming

Environment and compliance

TemperatureWorking temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Ingress protectionIP30 (when properly installed)
Humidity20% RH to 85% RH (no condensation)
CertificationCE, RoHS

Electrical

Drive modeConstant voltage
Strobe overdriveNot supported
Channel4
Trigger modeExternal trigger supported, Internal trigger
Input voltage100 ~ 240 VAC, 50/60 Hz
Input current1.4 A
Output current5 A max
Output power120 W max
Output current for each channel3 A max
Trigger inLevel signal DC 5 to 24 V / 6 mA
Trigger outNot supported
Output voltage24 VDC

Mechanical

Dimension104.8 mm × 95 mm × 180 mm
Shell materialPlastic
WeightApprox. 700 g
Shipping weight (estimated)1.08 kg
