HAPC analog power supply controller (high power), 2 ch (LS-HHAPC48400-2T)

Model LS-HHAPC48400-2T

Channels2
Output0-24 V
InputAC100-240V 50/60Hz
Total output8.4A
ControlMulti-turn knob

$139.00

In stock - ships the same business day (2 available, order by 2 PM ET)

2.35 kg shipping weight

Volume pricing, Net 30 or a formal quote?

HAPC series high-power controllers provide brightness-control power for high-power 24 V LED lights, with a built-in high-power switching power supply, high-speed isolated trigger with trigger-on / trigger-off, and stepless knob adjustment on the front panel; stable, convenient, fast high-power controllers for industrial lighting.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-HHAPC48400-2T
Control	Multi-turn knob
Front panel (LS-HHAPC24400P-1T / LS-HHAPC24500P-1T)	Multi-turn knob, trigger port (EXT TRI), on/off switch, power switch, ground terminal, two aviation light outputs
Control (perform)	Knob

Electrical

Input voltage	AC100-240V 50/60Hz
Output voltage	0-24 V
Channel / output	C2 O4 (2 channels, 4 outputs)
Single channel current	4.2A
Total output current	8.4A
Trigger input	No
Channels	2

Mechanical

Shipping weight	2.35 kg

Other models in the HAPC analog power supply controller (high power) series

See all 4 models

Model	Size / key data	Price	Availability	Link
LS-HHAPC24400P-1T	1 ch	$119.00	5 in stock	View
LS-HHAPC48550-1T	1 ch	$119.00	4 in stock	View
LS-HHAPC24500P-1T	1 ch	$129.00	4 in stock	View
