Representative photo of this series
Backlights
180 x 54 mm traditional surface light source (LS-FL50180)
Model LS-FL50180
- ColourRed, Green, Blue, White, Infrared, UV
- Voltage24 V DC (12 V on request)
- TypeStandard
- Length180 mm
$99.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.35 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Surface light with large-area uniform light emission and high-array LED arrangement for high-brightness planar lighting. Mainly used for perspective contour imaging and large-format uniform illumination.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FL50180 |
|---|
Electrical
| Voltage | 24 V DC (12 V on request) |
|---|---|
| Power red (W) | 8.5 |
| Power white/blue/green (W) | 11 |
Mechanical
| Length (mm) | 180 |
|---|---|
| Width (mm) | 54 |
| Height (mm) | 15 |
| Shipping weight | 0.35 kg |
