Machine vision lenses

Macro lens, 1.1" 12MP, 75 mm, C-Mount (LS-FFL-1522)

Model LS-FFL-1522

Focal length75 mm
MountC-mount
Sensor1.1"
Working distance257-471 mm
ApertureF3.8-16
Resolution12MP

$589.00

Ships in 2-3 weeks

0.38 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

12MP macro lenses designed for precise imaging with limited space, working distance 52-546 mm, with a large image circle suitable for IMX253LLR (1.1" 12MP); EFL 16-75 mm, magnification 0.03x-0.8x, ultra-low distortion (<0.05%).

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-FFL-1522
F/NO	2.8-16
EFL	75mm
O/I	357-557

Optics

Distortion	<0.05%
Image size	1.1"
Image size (dia.)	1.1"
Optical magnification	-0.38X~-0.18X
Distortion (TV)	<0.05%
Working distance	257-471
Focal length (mm)	75
Aperture	F3.8-16

Sensor and imaging

Resolution	12MP
Sensor format	1.1"

Mechanical

Mount	C-Mount
Filter size	M27×P0.5
Shipping weight	0.38 kg

Downloads

Datasheet (PDF)LS-FFL-1522 · 1.3 MB

Features

High resolution up to 12MP
Designed for precise imaging with limited space, WD from 52mm to 546mm
Large image circle, suitable for IMX253LLR (1.1" 12MP)
EFL range from 16mm to 75mm
Magnification range from 0.03x-0.8x
Ultra-low distortion (<0.05%)
High contrast, low distortion

Applications

Industrial: blemish / stain - inspect steel plate for defects and blemishes
Electronic component: yes or no / identify - check the number of tiny chips and poor imprint
Electronic component: blemish / stain - detecting camera defects
Electronic equipment: yes or no / identify - detect poor binding and lead breakage of motor wires

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer

Other models in the Macro lens, 1.1" 12MP (LS-FFL-S143) series

See all 5 models

Model	Size / key data	Price	Availability	Link
LS-FFL-1518	16 mm, 1.1", C-Mount	$489.00	Ships in 2-3 weeks	View
LS-FFL-1519	25 mm, 1.1", C-Mount	$499.00	Ships in 2-3 weeks	View
LS-FFL-1520	35 mm, 1.1", C-Mount	$519.00	Ships in 2-3 weeks	View
LS-FFL-1521	50 mm, 1.1", C-Mount	$549.00	Ships in 2-3 weeks	View
