Representative photo of this series
Machine vision lenses
Large format lens, 60 mm, F-Mount (LS-FFL-1504)
Model LS-FFL-1504
- Focal length60 mm
- Magnification0.01X-0.4X
- MountF-mount
- SensorLarge format
- Working distance384.9 mm
- ApertureF4.0-32
$1,189.00
Ships in 2-3 weeks
0.38 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Large format lenses with max image circle up to 43 mm, supporting 29MP sensors and suitable for 4K line scan cameras with 5 µ/7 µ pixels; better optical performance than SLR lenses, with standard EFL and magnification options, applied to printing and packaging inspection.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-1504 |
|---|---|
| EFL | 60mm |
| F/NO | 4.0-32 |
| Conjugate distance | 496.32 |
| Flange distance | 46.5 |
Optics
| Magnification range | 0.01X-0.4X |
|---|---|
| Distortion | <0.01% |
| Standard magnification | 0.167X |
| Image size (dia.) | dia. 64 |
| Optical distortion | 0.19% |
| Working distance | 384.9 |
| Focal length (mm) | 60 |
| Aperture | F4.0-32 |
Sensor and imaging
| Sensor format | dia. 64 mm image circle |
|---|
Mechanical
| Mount | F-Mount |
|---|---|
| Filter size | M65×P0.75 |
| Shipping weight | 0.38 kg |
Other models in the Large format lens (LS-FFL-S140) series
See all 7 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-FFL-1500 | 35 mm, F-Mount | $969.00 | Ships in 2-3 weeks | View |
| LS-FFL-1501 | 35 mm, F-Mount | $969.00 | Ships in 2-3 weeks | View |
| LS-FFL-1502 | 40 mm, F-Mount | $1,019.00 | Ships in 2-3 weeks | View |
| LS-FFL-1503 | 50 mm, F-Mount | $1,099.00 | Ships in 2-3 weeks | View |
| LS-FFL-1505 | 80 mm, F-Mount | $1,359.00 | Ships in 2-3 weeks | View |
| LS-FFL-1506 | 90 mm, F-Mount | $1,449.00 | Ships in 2-3 weeks | View |
