Machine vision lenses

Fixed lens for FA, 2/3" 10MP, 8 mm, C-Mount (LS-FFL-0689)

Model LS-FFL-0689

Focal length8 mm
MountC-mount
Sensor2/3"
ApertureF2.8-16
Resolution10MP
Field of view57.6° x 44°

$309.00

Ships in 2-3 weeks

0.38 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Ultra-high imaging quality fixed FA lenses for 2.4 µm pixel sensors, resolution up to 10MP, with high relative illumination and a big aperture in a small, ultra-compact design.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-FFL-0689
F/NO	2.8-16
EFL	8mm
MOD	0.1m

Optics

Distortion	<0.1%
Image size	2/3"
Image size (dia.)	2/3"
Field of view angle 2/3"	57.6° x 44°
Field of view angle 1/2"	42.8° x 32.7°
Field of view angle 1/3"	32.7° x 24.7°
Distortion (TV) 2/3"	<1%
Focal length (mm)	8
Aperture	F2.8-16

Sensor and imaging

Resolution	10MP
Sensor format	2/3"

Mechanical

Mount	C-Mount
Filter size	M30.5×P0.5
Shipping weight	0.38 kg

Downloads

Datasheet (PDF)LS-FFL-0689 · 1.2 MB

Features

Ultra-high imaging quality
Suitable for 2.4µ sensor, resolution up to 10MP
High relative illumination, with big aperture
Focus range from 0.1 m to infinity
Small size, ultra-compact design

Applications

Electronic component: yes or no / identify - check the presence of IC in the carrier band
Electronic equipment: blemish / stain - check the appearance of the battery outer tank
Electronic component: position / tilt - detect the defective conductor of the capacitor
Liquid crystal, semiconductor: position / tilt - positioning of the glass circuit board
