Representative photo of this series

Machine vision lenses

Industrial lens, 1" 5MP FA lens, 75 mm, C-mount (LS-FFL-0503)

Model LS-FFL-0503

Focal length75 mm
MountC-mount
Sensor1"
Aperture1.8
Resolution5
Field of view110.43 x 82.78*

$429.00

Ships in 2-3 weeks

0.38 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Industrial lens, 1" 5MP FA lens with mount C Mount, max image surface size 1", focal length 75, aperture 1.8, fov @ wd 200 110.43 x 82.78*.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-FFL-0503
Min distance	0.8M

Optics

Focal length (mm)	75
Aperture	1.8
TV distortion	<0.1%
Filter thread	M55 x P0.75
Field of view	110.43 x 82.78*

Sensor and imaging

FOV @ WD 200 (H x V), 1" sensor	110.43 x 82.78*
FOV @ WD 200 (H x V), 2/3" sensor	73.04 x 61.74*
FOV @ WD 200 (H x V), 1/2" sensor	55.65 x 41.74*
Sensor format	1"
Resolution (MP)	5

Interfaces and I/O

Interface	C Mount

Mechanical

Mount	C Mount
Max image surface size	1"
Shipping weight	0.38 kg

Other models in the Industrial lens, 1" 5MP FA lens (LS-FFL-S81) series

See all 6 models

Model	Size / key data	Price	Availability	Link
LS-FFL-0498	12.5 mm, 1", C-mount	$299.00	Ships in 2-3 weeks	View
LS-FFL-0499	16 mm, 1", C-mount	$309.00	Ships in 2-3 weeks	View
LS-FFL-0502	50 mm, 1", C-mount	$369.00	Ships in 2-3 weeks	View
LS-FFL-0501	35 mm, 1", C-mount	$449.00	Ships in 2-3 weeks	View
LS-FFL-0500	25 mm, 1", C-mount	$459.00	Ships in 2-3 weeks	View
