Machine vision lenses
35mm, F2.8, Image Size φ29mm, Recommended Magnification 0.001x ~ 0.164X, M42-Mount (LS-FFL-0423)
Model LS-FFL-0423
- Focal length35 mm
- Magnification0.164 x to 0.001 x
- MountM42
- SensorAPS-C
- Working distance200 mm to inf mm (tolerance: ±5 mm)
- ApertureF2.8 to F16
$639.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.31 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
35mm, F2.8, Image Size φ29mm, Recommended Magnification 0.001x ~ 0.164X, M42-Mount. Adopts high-precision lens for 8k 7 μm line scan cameras. Provides excellent consistency of image clarity and low distortion.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-0423 |
|---|
Optics
| Focal length | 35 mm |
|---|---|
| F-number | F2.8 to F16 |
| Image size | Φ29 mm |
| Optical distortion | –0.16% |
| Magnification range | 0.164 x to 0.001 x |
| Working distance range | 200 mm to inf mm (tolerance: ±5 mm) |
| Iris control | Manual |
| Focus control | Manual |
| Filter thread | M52 × P0.75 |
| Magnification at working distance (mm) | 200: -0.164; 250: -0.133; 300: -0.112; 350: -0.097; 400: -0.085; 450: -0.076; 500: -0.069; 550: -0.063; 600: -0.057; 650: -0.053; 700: -0.049; 750: -0.046; 800: -0.043; 850: -0.041; 900: -0.039; 950: -0.037; 1000: -0.035; 1100: -0.032; 1200: -0.029; 1300: -0.027; 1400: -0.025; 1500: -0.023 |
| Object-to-image distance at working distance (mm) | 200: 309; 250: 359; 300: 409; 350: 459; 400: 509; 450: 559; 500: 609; 550: 659; 600: 709; 650: 759; 700: 809; 750: 859; 800: 909; 850: 959; 900: 1009; 950: 1059; 1000: 1109; 1100: 1209; 1200: 1309; 1300: 1409; 1400: 1509; 1500: 1609 |
| Field of view H (mm) at working distance (mm), 4k 7 µm sensor | 200: 175.8; 250: 216.6; 300: 257.2; 350: 297.8; 400: 338.3; 450: 378.7; 500: 419.2; 550: 459.6; 600: 500.0; 650: 540.4; 700: 580.9; 750: 621.2; 800: 661.8; 850: 702.0; 900: 742.4; 950: 782.7; 1000: 823.1; 1100: 903.8; 1200: 984.5; 1300: 1065.3; 1400: 1146.0; 1500: 1226.7 |
Environment and compliance
| Temperature | –10 °C to 50 °C (14 °F to 122 °F) |
|---|---|
| Certification | RoHS 2.0 |
Mechanical
| Mount | M42 × P1 |
|---|---|
| Flange back length | 12 mm |
| Dimension | Φ55 mm × 102.5 mm (Φ2.2" × 4.0") |
| Shipping weight (estimated) | 0.31 kg |
