Light controllers
High power constant current controller, 2 ch, 400 W (LS-CTL-0307)
Model LS-CTL-0307
- Channels2
- InputAC 100-240V
- Total output400W
- ControlRS232, LAN
$599.00
Ships in 2-3 weeks
2.95 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
High power constant current controller: each channel controlled independently with high precision, digital display and button control, RS232/LAN communication with PC, trigger input and power-off saving.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-CTL-0307 |
|---|
Interfaces and I/O
| Communication | RS232, LAN |
|---|
Light
| Luminance control method | manual adjust by button, PC remote adjustment |
|---|---|
| Luminance control mode | Constant-current |
| Luminance control level | 256 level |
Computing
| Storage function | luminance kept when power off |
|---|
Electrical
| Input frequency | 43-67Hz |
|---|---|
| External trigger voltage | high level 5-24V |
| Fan supply output | 24V 2A |
| Baud rate | 9600bps |
| Channels | 2 |
| Single channel output current | 0-8A |
| One way max. output power | 200W |
| Total output power | 400W |
| External trigger support | Y |
| Input voltage | AC 100-240V |
Mechanical
| Shipping weight | 2.95 kg |
|---|
Other models in the High power constant current controller (LS-CTL-S57) series
See all 6 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-CTL-0305 | 1 ch, 200 W | $409.00 | Ships in 2-3 weeks | View |
| LS-CTL-0306 | 1 ch, 400 W | $559.00 | Ships in 2-3 weeks | View |
| LS-CTL-0308 | 1 ch, 500 W | $619.00 | Ships in 2-3 weeks | View |
| LS-CTL-0309 | 1 ch, 800 W | $809.00 | Ships in 2-3 weeks | View |
| LS-CTL-0310 | 1 ch, 1200 W | $1,059.00 | Ships in 2-3 weeks | View |
