Standard digital controller (LS-CTL-S52 series, incl. high power)
  • Standard digital controller (LS-CTL-S52 series, incl. high power)
  • LS-CTL-0243 dimensions (mm)

Representative photo of this series

Light controllers

Standard digital controller (LS-CTL-S52 series, incl. high power), 1 ch, 200 W (LS-CTL-0239)

Model LS-CTL-0239

  • Channels1
  • OutputDC14.0V~24.0V
  • Input100-220V AC
  • Total output200 W
  • Control9600
$389.00

Ships in 2-3 weeks

0.5 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

Standard digital controller (LS-CTL-S52 series, incl. high power), 1 ch, 200 W (LS-CTL-0239)LS-CTL-0239

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Standard digital constant-current light controller (ordinary type), 1, 2 or 4 channels up to 600 W per channel; current control makes LED brightness more stable so the camera takes pictures without stroboscopic phenomenon. The controller provides power to the light source and controls its brightness and lighting state (on, off); a trigger signal to the controller strobes the light source and prolongs its life. Digital controllers can be controlled remotely by PC equipment.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-CTL-0239
Type of driveConstant current
Manual adjustmentyes (adjust by key)
Remote adjustmentyes (through the upper computer software)
ControlDigital

Interfaces and I/O

RS232 communication baud rate9600

Light

Luminance level memoryyes (memory automatically remembered 8 seconds after adjustment)
Adjustable brightness levelLevel 255 (long press rough adjustment, short press fine adjustment; also adjustable by PC software)

Environment and compliance

Work environmentTemperature: -10~50 °C, Humidity: 20~80%RH non-solidification
Storage environmentTemperature: -20~70 °C, Humidity: 10~55%RH non-solidification

Electrical

Input voltage100-220V AC
Output voltage rangeDC14.0V~24.0V
External trigger modePassive trigger, high and low level trigger can be switched (effective trigger voltage range 5-24V DC; 6-24V DC on the 4-channel high power page)
External trigger delay timeH, ON→OFF <60us; H, OFF→ON <60us; L, ON→OFF <80us; L, OFF→ON <80us
External trigger frequency<1/T (e.g. T=1ms gives at most 1KHz)
Standby power consumption<1W
Power/CH200W
Output voltage24V
External triggeryes
Channels1
Total output (W)200

Mechanical

Shipping weight0.50 kg

Other models in the Standard digital controller (LS-CTL-S52 series, incl. high power) series

See all 11 models
ModelSize / key dataPriceAvailabilityLink
LS-CTL-0243 2 ch $339.00 Ships in 2-3 weeks View
LS-CTL-0241 1 ch $359.00 Ships in 2-3 weeks View
LS-CTL-0244 2 ch, 200 W $469.00 Ships in 2-3 weeks View
LS-CTL-0240 1 ch, 300 W $489.00 Ships in 2-3 weeks View
LS-CTL-0245 2 ch, 300 W $539.00 Ships in 2-3 weeks View
LS-CTL-0246 2 ch, 400 W $559.00 Ships in 2-3 weeks View
LS-CTL-0248 4 ch, 200 W $569.00 Ships in 2-3 weeks View
LS-CTL-0242 1 ch, 600 W $639.00 Ships in 2-3 weeks View
LS-CTL-0249 4 ch, 320 W $639.00 Ships in 2-3 weeks View
LS-CTL-0247 2 ch, 600 W $779.00 Ships in 2-3 weeks View
