Bar Light, 700 x 30 mm, IR 850 nm (LS-BAR-1191)
Model LS-BAR-1191
- ColourInfrared
- Emitting area636 mm × 21.6 mm
- Size648 mm × 30 mm × 30 mm
- Voltage24 VDC
- Power39.4 W
- Wavelength850 nm
$669.00
Ships in 2-3 weeks
1.7 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Bar Light, 700 x 30 mm, IR 850 nm. The irradiation direction and angle can be adjusted freely. Support multi-side installation.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-BAR-1191 |
|---|---|
| Safety class | No danger |
| Cooling mode | Natural cooling |
Optics
| Best working distance | 30 mm to 500 mm |
|---|
Interfaces and I/O
| Connector type | SMR-03V-B |
|---|---|
| Cable length | 1 m |
Light
| Color | IR850 |
|---|---|
| Center illuminance/irradiance | ≥ 2260 μW/cm2@100 mm |
| Wavelength | 850 nm |
| Color temperature | W: 6000K to 7500K |
| Emitting area dimension | 636 mm × 21.6 mm |
| LED rows | 4 |
| Diffuse plate included | PMMA |
Environment and compliance
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
|---|---|
| Humidity | 20% RH to 90% RH (no condensation) |
Electrical
| Power | 39.4 W |
|---|---|
| Input voltage | 24 VDC |
Mechanical
| Dimension | 648 mm × 30 mm × 30 mm |
|---|---|
| Weight | 1.14 kg |
| Shipping weight (estimated) | 1.70 kg |
