Bar lights
Bar Light, 600 x 30 mm, IR 940 nm (LS-BAR-1182)
Model LS-BAR-1182
- ColourInfrared
- Emitting area546 mm × 21.6 mm
- Size558 mm × 30 mm × 30 mm
- Voltage24 VDC
- Power51.6 W
- Wavelength940 nm
$629.00
Ships in 2-3 weeks
1.47 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Bar Light, 600 x 30 mm, IR 940 nm. The irradiation direction and angle can be adjusted freely. Support multi-side installation.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-BAR-1182 |
|---|---|
| Safety class | No danger |
| Cooling mode | Natural cooling |
Optics
| Best working distance | 30 mm to 500 mm |
|---|
Interfaces and I/O
| Connector type | SMR-03V-B |
|---|---|
| Cable length | 1 m |
Light
| Color | IR940 |
|---|---|
| Center illuminance/irradiance | ≥ 2800 μW/cm2@100 mm |
| Wavelength | 940 nm |
| Color temperature | W: 6000K to 7500K |
| Emitting area dimension | 546 mm × 21.6 mm |
| LED rows | 4 |
| Diffuse plate included | PMMA |
Environment and compliance
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
|---|---|
| Humidity | 20% RH to 90% RH (no condensation) |
Electrical
| Power | 51.6 W |
|---|---|
| Input voltage | 24 VDC |
Mechanical
| Dimension | 558 mm × 30 mm × 30 mm |
|---|---|
| Weight | 0.98 kg |
| Shipping weight (estimated) | 1.47 kg |
