Bar lights
Bar Light, 300 x 40 mm, White (LS-BAR-1139)
Model LS-BAR-1139
- ColourWhite
- Emitting area276 mm × 31.6 mm
- Size288 mm × 40 mm × 30 mm
- Voltage24 VDC
- Power31.3 W
$309.00
Ships in 2-3 weeks
0.9 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Bar Light, 300 x 40 mm, White. The irradiation direction and angle can be adjusted freely. Support multi-side installation.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-BAR-1139 |
|---|---|
| Safety class | No danger |
| Cooling mode | Natural cooling |
Optics
| Best working distance | 30 mm to 500 mm |
|---|
Interfaces and I/O
| Connector type | SMR-03V-B |
|---|---|
| Cable length | 1 m |
Light
| Color | White |
|---|---|
| Center illuminance/irradiance | ≥ 30000 lux@100 mm |
| Color temperature | W: 6000K to 7500K |
| Emitting area dimension | 276 mm × 31.6 mm |
| LED rows | 6 |
| Diffuse plate included | PMMA |
Environment and compliance
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
|---|---|
| Humidity | 20% RH to 90% RH (no condensation) |
Electrical
| Power | 31.3 W |
|---|---|
| Input voltage | 24 VDC |
Mechanical
| Dimension | 288 mm × 40 mm × 30 mm |
|---|---|
| Weight | 0.57 kg |
| Shipping weight (estimated) | 0.90 kg |
Other models in the Bar lights (LS-BAR-S99) series
See all 172 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-BAR-1121 | 250 x 30 mm, IR 850 nm | $289.00 | Ships in 2-3 weeks | View |
| LS-BAR-1122 | 250 x 30 mm, IR 940 nm | $289.00 | Ships in 2-3 weeks | View |
| LS-BAR-1129 | 250 x 40 mm, White | $289.00 | Ships in 2-3 weeks | View |
| LS-BAR-1128 | 250 x 40 mm, Red | $289.00 | Ships in 2-3 weeks | View |
| LS-BAR-1125 | 250 x 40 mm, Blue | $289.00 | Ships in 2-3 weeks | View |
| LS-BAR-1126 | 250 x 40 mm, IR 850 nm | $289.00 | Ships in 2-3 weeks | View |
| LS-BAR-1127 | 250 x 40 mm, IR 940 nm | $289.00 | Ships in 2-3 weeks | View |
| LS-BAR-1134 | 300 x 30 mm, White | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1133 | 300 x 30 mm, Red | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1130 | 300 x 30 mm, Blue | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1131 | 300 x 30 mm, IR 850 nm | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1132 | 300 x 30 mm, IR 940 nm | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1138 | 300 x 40 mm, Red | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1135 | 300 x 40 mm, Blue | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1136 | 300 x 40 mm, IR 850 nm | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1137 | 300 x 40 mm, IR 940 nm | $309.00 | Ships in 2-3 weeks | View |
| LS-BAR-1114 | 200 x 30 mm, White | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-1110 | 200 x 30 mm, Blue | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-1113 | 200 x 30 mm, Red | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-1111 | 200 x 30 mm, IR 850 nm | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-1112 | 200 x 30 mm, IR 940 nm | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-1119 | 200 x 40 mm, White | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-1118 | 200 x 40 mm, Red | $319.00 | Ships in 2-3 weeks | View |
| LS-BAR-1115 | 200 x 40 mm, Blue | $319.00 | Ships in 2-3 weeks | View |
