Bar Light, 200 x 40 mm, White (LS-BAR-1119)
  • Bar Light, 200 x 40 mm, White (LS-BAR-1119)
  • LS-BAR-1119 dimensions (mm)

Bar lights

Bar Light, 200 x 40 mm, White (LS-BAR-1119)

Model LS-BAR-1119

  • ColourWhite
  • Emitting area186 mm × 31.6 mm
  • Size198 mm × 40 mm × 30 mm
  • Voltage24 VDC
  • Power20.9 W
$319.00

Ships in 2-3 weeks

0.67 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

Bar Light, 200 x 40 mm, White (LS-BAR-1119)LS-BAR-1119

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Bar Light, 200 x 40 mm, White. The irradiation direction and angle can be adjusted freely. Support multi-side installation.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-BAR-1119
Safety classNo danger
Cooling modeNatural cooling

Optics

Best working distance30 mm to 500 mm

Interfaces and I/O

Connector typeSMR-03V-B
Cable length1 m

Light

ColorWhite
Center illuminance/irradiance≥ 30000 lux@100 mm
Color temperatureW: 6000K to 7500K
Emitting area dimension186 mm × 31.6 mm
LED rows6
Diffuse plate includedPMMA

Environment and compliance

TemperatureWorking temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Humidity20% RH to 90% RH (no condensation)

Electrical

Power20.9 W
Input voltage24 VDC

Mechanical

Dimension198 mm × 40 mm × 30 mm
Weight0.41 kg
Shipping weight (estimated)0.67 kg
