4-Channel High-Power Analog LED Light Controller, 0-48V (LS-APC481600-2H)
Model LS-APC481600-2H
- Output0~48V
- InputAC100-240V 50/60Hz
- Total output34A
- Channels4 channels
In stock - ships the same business day (3 available, order by 2 PM ET)
0.5 kg shipping weight
Volume pricing, Net 30 or a formal quote?
4-Channel High-Power Analog LED Light Controller, 0-48V. APC series analog controller mainly powers 24V LED lights (as stated; the range also includes 48V-output models); brightness is adjusted accurately with the front-panel stepless knob. It can keep the light continuously on for a long time and has a built-in external trigger function for easy on-off switching.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-APC481600-2H |
|---|---|
| Control method | knob |
| Knob | Lockable intensity knob (rotate right to lock, left to unlock) |
| Ground terminal | Yes |
Electrical
| Output CH | 4CH |
|---|---|
| Input voltage | AC100-240V 50/60Hz |
| Output voltage | 0~48V |
| Single CH current | 10A/17A |
| Total output current | 34A |
| External trigger voltage | 5-24V |
| Trigger port (trigger models) | DC 5-24V trigger input; 1 = CH1, 2 = CH2, COM = common, NC = blank; COM cannot connect to + and - at the same time |
| ON/OFF switch (trigger models) | H = constant on (trigger turns light off); L = constant off (trigger turns light on) |
| Power switch | I = on, O = off |
Mechanical
| Shipping weight (estimated) | 0.50 kg |
|---|
Mounting and drawing data
Trigger port + H/L switch; outputs 25M-4A and 19M-4A (48 V light +/-, 24 V fan +/-); panel label 100-240 VAC. Drawing: connector-panel view 157 (150) x 300 mm; second view 304.5 (280 body, 230 hole pitch) x 250 hole pitch with 4 x M3 feet.
