Representative photo of this series
Special lights
150 mm dia. AOI light (LS-AOI10375-15060)
Model LS-AOI10375-15060
- ColourRed, Green, Blue, White, Infrared, UV
- Voltage24 V DC (12 V on request)
- TypeAOI
- Number of lamp rows4
$759.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.9 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Multiple colours and multi-angle illumination, highlighting the surface layer information of objects.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-AOI10375-15060 |
|---|---|
| Number of lamp rows | 4 |
Interfaces and I/O
| Cable length (mm) | 500 |
|---|
Electrical
| Voltage | 24 V DC (12 V on request) |
|---|---|
| Power red (W) | 10.1 |
| Power white/blue/green (W) | 18.8 |
Mechanical
| Outer diameter (mm) | 150 |
|---|---|
| Inner diameter (mm) | 56 |
| Height (mm) | 43.5 |
| Mounting | 4 x M3 threaded, depth 6 |
| Shipping weight | 0.90 kg |
Other models in the AOI light (LS-AOI) series
See all 6 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-AOI774028-RRBB | 77 mm dia. | $559.00 | 2 in stock | View |
| LS-AOI5090-7430 | 74 mm dia. | $599.00 | 25 in stock | View |
| LS-AOI5090-7460-9030 | 88 mm dia. | $649.00 | 26 in stock | View |
| LS-AOI12090-16045 | 80 mm dia. | $789.00 | 18 in stock | View |
| LS-AOI10375-15060-18030 | 130 mm dia. | $909.00 | 20 in stock | View |
