Representative photo of this series
Light controllers
Alternate strobe controller, 2 ch, 2000 W (LS-3DRC481000-2N)
Model LS-3DRC481000-2N
- Channels2
- Output48V
- InputAC 100-240V
- Total output2000W
- ControlRS232/LAN
$1,019.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.5 kg shipping weight
Volume pricing, Net 30 or a formal quote?
Use with line scan light. Time-sharing alternate / independent trigger mode optional. Differential / TTL trigger signal optional.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-3DRC481000-2N |
|---|---|
| Product | Alternate strobe controller |
| Control | Manual adjustment by encoder, PC remote adjustment |
Interfaces and I/O
| Communication mode | RS232/LAN |
|---|
Light
| LED lighting time | 5-68us/5-500us (alternate trigger mode); 5-999us (independent trigger mode) |
|---|---|
| Luminance adjustment mode | Constant voltage |
| Luminance adjustment level | 512/1000 level |
| Luminance adjustment method | Manual adjustment by encoder, PC remote adjustment |
Environment and compliance
| Operating environment | Humidity 20%-85%RH (non-condensing), temperature 0°C-50°C |
|---|---|
| Storage environment | Humidity 20%-85%RH (non-condensing), temperature 0°C-60°C |
Computing
| Memory function | Data saving automatically when power off |
|---|
Electrical
| Input voltage | AC 100-240V |
|---|---|
| Input frequency range | 50/60Hz |
| Baud rate | 19200bps |
| External input trigger signal | TTL or DIFF signal (both rising edge effective, DIFF signal only supports 5V), max. external trigger frequency up to 80KHz |
| Output camera trigger signal | TTL or DIFF signal |
| External trigger signal | 5V-24V (high level effective) |
| External trigger delay time | 5us |
| External trigger voltage | 5-24V |
| Output voltage | 48V |
| Total output power | 2000W |
| One way max. output power | 1000W |
| Number of channels | 2 |
Mechanical
| Shipping weight | 0.50 kg |
|---|
Other models in the Alternate strobe controller (3DRC) series
See all 5 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-3DRC24250-2N | 2 ch, 250 W | $179.00 | 4 in stock | View |
| LS-3DRC24250-4N | 4 ch, 250 W | $209.00 | 5 in stock | View |
| LS-3DRC48400-2N | 2 ch, 400 W | $319.00 | 2 in stock | View |
| LS-3DRC48400-4N | 4 ch, 400 W | $359.00 | 4 in stock | View |
