Light controllers
Analog controller box, 2 ch, 60 W (LS-3APC2460-2F)
Model LS-3APC2460-2F
- Channels2 Way
- Output24V
- InputDC 24V
- Total output60W
- ControlManual adjustment
$119.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.5 kg shipping weight
Volume pricing, Net 30 or a formal quote?
DC24V input. Stepless adjustable output voltage. Compact size.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-3APC2460-2F |
|---|---|
| Constant on / off switch | Support |
| Product | Analog controller box |
| Control | Manual adjustment |
Light
| Luminance adjustment level | Stepless (knob adjustment) |
|---|---|
| Luminance adjustment method | Manual adjustment |
| Luminance adjustment mode | Constant current mode |
Electrical
| External trigger voltage | 0-1.5V |
|---|---|
| Number of channels | 2 Way |
| Input voltage | DC 24V |
| Output voltage | 24V |
| Total output power | 60W |
| One way max. output power | 30W |
Mechanical
| Mounting | DIN rail mount |
|---|---|
| Shipping weight | 0.50 kg |
