Backlights
Ultrathin flank back light, 490 x 490 x 9.5 mm (LS-2FTC450450)
Model LS-2FTC450450
- ColourRed, Blue, Green, White
- Emitting area450 x 450 mm
- SizeL490xW490xH9.5(mm)
- Voltage24V
- Power30.8W/38.4W
$889.00
In stock - ships the same business day (5 available, order by 2 PM ET)
2.65 kg shipping weight
Volume pricing, Net 30 or a formal quote?
A stable structure combined with ultra-thin thickness. Easy to install in the narrow space. High uniformity.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-2FTC450450 |
|---|---|
| Note | UV & IR light can be customized as required. |
Interfaces and I/O
| Cable (mm) | 300 (drawing) |
|---|
Light
| LED colour | R(red)/W(white) |
|---|---|
| Emitting surface (mm) | 450 x 450 |
Electrical
| Voltage | 24V |
|---|---|
| Power | 30.8W/38.4W |
| Input voltage | DC 24V (max) |
Mechanical
| Dimension | L490xW490xH9.5(mm) |
|---|---|
| Shipping weight | 2.65 kg |
Other models in the Ultrathin flank back light (2FTC) series
See all 10 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-2FTC3030 | Red, Blue, Green, White · L70xW70xH9.5(mm) | $89.00 | 14 in stock | View |
| LS-2FTC5050 | Red, Blue, Green, White · L90xW90xH9.5(mm) | $99.00 | 10 in stock | View |
| LS-2FTC6060 | Red, Blue, Green, White · L100xW100xH9.5(mm) | $99.00 | 11 in stock | View |
| LS-2FTC100100 | Red, Blue, Green, White · L140xW140xH9.5(mm) | $139.00 | 13 in stock | View |
| LS-2FTC150150 | Red, Blue, Green, White · L190xW190xH9.5(mm) | $189.00 | 14 in stock | View |
| LS-2FTC200200 | Red, Blue, Green, White · L240xW240xH9.5(mm) | $259.00 | 16 in stock | View |
| LS-2FTC250250 | Red, Blue, Green, White · L290xW290xH9.5(mm) | $349.00 | 11 in stock | View |
| LS-2FTC300300 | Red, Blue, Green, White · L340xW340xH9.5(mm) | $459.00 | 10 in stock | View |
| LS-2FTC360360 | Red, Blue, Green, White · L400xW400xH9.5(mm) | $609.00 | 14 in stock | View |
