Rendered illustration: the actual product may differ in appearance.
Machine vision lenses
4 - 10 mm lens, 1/1.8", CS-mount (LS-ZML-0014)
Model LS-ZML-0014
Machine vision lens for industrial cameras. Minimum object distance 1000 mm.
Specifications
| Model | LS-ZML-0014 |
|---|---|
| Focal length | 4 - 10 mm |
| Magnification | 2.5× |
| Sensor format | 1/1.8" |
| Mount | CS-Mount |
| Minimum object distance | 1000 mm |
| Aov @ 1/1.8″ (16:9) h°×v°×d° | 120.1 × 62.1 × 147.8° 46.3 × 25.9 × 53.3° |
| Aperture (max) | f/0.9 |
| Back focal length | 8.01 mm |
| Dimensions | 63.5 × 63.5 × 77.9 mm |
| Filter thread | No Filter Threads |
| Focus control | Manual |
| Front diameter | 33.9 mm |
| Image circle | 8.9 mm |
| Image size dimensions | 7.1 mm x 5.4 mm |
| Iris control | Stepper Motor |
| Lens type | Variable Focal Length |
| Operating temperature range | -20 to +60 °C |
| Rear effective diameter | 10.7 mm |
| Resolution (MP) | 8 |
| Spectrum | Visible + NIR |
| Zoom control | Manual |
| Zoom range | 4 mm - 10 mm |
| Weight | 16.3 |
