Home / Lenses / Machine vision lenses / 4 - 10 mm lens, 1/1.8", CS-Mount

4 - 10 mm lens, 1/1.8", CS-Mount (LS-ZML-0013)

Rendered illustration: the actual product may differ in appearance.

Machine vision lenses

4 - 10 mm lens, 1/1.8", CS-Mount (LS-ZML-0013)

Model LS-ZML-0013

4 - 10 mm lens, 1/1.8", CS-Mount. Minimum object distance 1000 mm. Aperture f/0.9 to f/360.

Datasheet (PDF) - LS-ZML-0013 3D model (STEP) - LS-ZML-0013

Specifications

Model	LS-ZML-0013
Filter Thread	No Filter Threads
Focal Length	4 - 10 mm
Front Diameter	33.9 mm
Image Circle Diameter	8.9 mm
Image Size Dimensions	7.1 mm x 5.4 mm
Imager Format	1/1.8"
Lens Type	Variable Focal Length
Light Spectrum	Visible + NIR
Magnification	2.5×
Minimum Object Distance	1000 mm
Mount	CS-Mount
Resolution (MP)	8
ƒ/N Max	f/0.9
ƒ/N Min	f/360

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
