8.5 - 50 mm lens, 1/2.7", CS-Mount (LS-ZML-0010)

Rendered illustration: the actual product may differ in appearance.

Machine vision lenses

8.5 - 50 mm lens, 1/2.7", CS-Mount (LS-ZML-0010)

Model LS-ZML-0010

8.5 - 50 mm lens, 1/2.7", CS-Mount. Minimum object distance 1000 mm. Aperture f/1.6 to f/360.

Datasheet (PDF) - LS-ZML-0010

Specifications

Model	LS-ZML-0010
Filter Thread	M40.5-0.5
Focal Length	8.5 - 50 mm
Focus Range	1 m - ∞
Front Diameter	21.7 mm
Image Circle Diameter	6.6 mm
Image Size Dimensions	3.2 mm x 5.8 mm
Imager Format	1/2.7"
Lens Type	Variable Focal Length
Light Spectrum	Visible + NIR
Magnification	6×
Minimum Object Distance	1000 mm
Mount	CS-Mount
Resolution (MP)	3
ƒ/N Max	f/1.6
ƒ/N Min	f/360
