Home / Lenses / Machine vision lenses / 2.8 - 10 mm lens, 1/2.7", CS-Mount

2.8 - 10 mm lens, 1/2.7", CS-Mount (LS-ZML-0007)

Rendered illustration: the actual product may differ in appearance.

Machine vision lenses

2.8 - 10 mm lens, 1/2.7", CS-Mount (LS-ZML-0007)

Model LS-ZML-0007

2.8 - 10 mm lens, 1/2.7", CS-Mount. Minimum object distance 1000 mm. Aperture f/1.4 to f/16.

Datasheet (PDF) - LS-ZML-0007

Specifications

Model	LS-ZML-0007
Filter Thread	M40.5-0.5
Focal Length	2.8 - 10 mm
Focus Range	1 m - ∞
Front Diameter	21.7 mm
Image Circle Diameter	6.6 mm
Image Size Dimensions	3.2 mm x 5.8 mm
Imager Format	1/2.7"
Lens Type	Variable Focal Length
Light Spectrum	Visible + NIR
Magnification	4×
Minimum Object Distance	1000 mm
Mount	CS-Mount
Resolution (MP)	3
ƒ/N Max	f/1.4
ƒ/N Min	f/16

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
