Machine vision lenses
1.1" 25 megapixel ultra-high resolution FA lens, 75 mm, 1.1", C-mount (LS-XR-7520MP)
Model LS-XR-7520MP
1.2" 25 megapixel ultra-high resolution lens (1.2" 25 MP fixed-focus lens); the parameter table lists sensor size 1.1" dia. 18.5 mm.
Features
- Supports cameras with sensors up to 1.1" (dia. 19.5 mm)
- Excellent low-distortion, high-resolution optical design
- Very large aperture design for ultra-high-speed on-the-fly capture
Specifications
| Model | LS-XR-7520MP |
|---|---|
| Mount | C |
| Fastening mode | Manual |
| Service temperature | 20°C~+60°C |
| Focal length | 75mm |
| Iris (F) | 2.8 |
| Filter screw size | M27 P=0.5MM |
| Sensor size | 1.1" φ18.5mm |
| Sensor format | 1.1" |
| Resolution (MP) | 25 |
| Aperture | F2.8 |
| Shipping weight | 0.38 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the 1.1" 25 megapixel ultra-high resolution FA lens series
| Model | Size | Price | Availability | |
|---|---|---|---|---|
| LS-XR-1220MP | 12 mm, 1.1", C-mount | $449.00 | 4 in stock | View |
| LS-XR-1620MP | 16 mm, 1.1", C-mount | $459.00 | 2 in stock | View |
| LS-XR-2520MP | 25 mm, 1.1", C-mount | $469.00 | 4 in stock | View |
| LS-XR-3520MP | 35 mm, 1.1", C-mount | $479.00 | 5 in stock | View |
| LS-XR-5020MP | 50 mm, 1.1", C-mount | $499.00 | 4 in stock | View |
