Telecentric lenses
Variable iris bi-telecentric lens (VCA230), 0.5x, WD 65 mm, 2/3", C-Mount (LS-VCA230-22C)
Model LS-VCA230-22C
Variable iris bi-telecentric lenses for up to 2/3" (8M pixel) cameras: zero perspective error over the entire field of view, big depth of field with constant magnification, and a manual iris for adjusting the depth of field.
Features
- Support up to 8M Pixel cameras
- Zero perspective error over the entire Field of View
- Big depth of field and constant magnification over defined depth of field
- Customization available with best performance/ cost rate
- Equipped with a Manual Iris for adjusting the Depth of Field.
Specifications
| Model | LS-VCA230-22C |
|---|---|
| Magnification (x) | 0.5 |
| Object Field of View (dia. mm) | 22 |
| Working Distance (mm) | 65±1 |
| Max Sensor Size (dia. mm) | 11.0(2/3") |
| Best Aperture (F/#) | 5.0 |
| Telecentricity typical (max) (deg) | <0.1 |
| Distortion typical (max) (%) | <0.1 |
| MTF30 (lp/mm) | >160 |
| Depth of Field (mm) | ±0.8@F5 |
| Length of I/O (mm) | 189±1 |
| Mount | C |
| Length(mm) | 106.7 |
| Weight(kg) | 0.2 |
| Coaxial Light | Yes |
| Iris | No |
| FOV with 8.47x7.10 with ICX625/655 (mm x mm) | 16.9x14.2 |
| Field of view with ICX625/655 (8.47x7.10 sensor) (mm x mm) | 16.9x14.2 |
| Sensor format | 2/3" |
