Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.133× Vertical telecentric lens, 2/3", C-mount (LS-TCL-0443)
Model LS-TCL-0443
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 132.9 mm.
Specifications
| Model | LS-TCL-0443 |
|---|---|
| Magnification | 0.133× Vertical |
| Working distance | 132.9 mm |
| Sensor format | 2/3" |
| Mount | C-Mount |
| Dimensions approximate | 200.6 x 75 x 75 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.05 |
| Filter thread | No Filter Threads |
| Fov detector long side horizontal @ 1/1.8″ | 038.54 x 28.81 mm - 38.54 x 29.78 mm - 38.54 x 33.11 mm - 38.54 x 40.08 |
| Fov detector long side horizontal @ 1/2.0″ | 34.59 x 25.95 - 34.59 x 26.82 - 34.59 x 29.81 - 34.59 x 36.09 |
| Fov detector long side horizontal @ 1/2.5″ | 30.81 x 23.14 - 30.81 x 23.91 - 30.81 x 26.58 - 30.81 x 32.18 |
| Fov detector long side horizontal @ 1/2″ | 34.59 x 25.95 34.59 x 26.82 34.59 x 29.81 34.59 x 36.09 |
| Fov detector long side horizontal @ 1/3.0″ | 25.95 x 19.4 mm - 625.95 x 20.11 mm - 25.95 x 22.36 mm - 25.95 x 27.07 mm |
| Fov detector long side horizontal @ 1/3″ | 25.95 x 19.4 mm 625.95 x 20.11 mm 25.95 x 22.36 mm 25.95 x 27.07 mm |
| Fov detector long side horizontal @ 2/3.0″ | 45.95 x 38.32 mm - 45.95 x 39.61 mm - 45.95 x 44.04 mm - 45.95 x 53.31 mm |
| Fov detector long side horizontal @ 2/3″ | 45.95 x 38.32 mm 45.95 x 39.61 mm 45.95 x 44.04 mm 45.95 x 53.31 mm |
| Fov detector long side vertical @ 1/1.8″ | 25.95 x 23.14 mm - 26.82 x 23.14 mm - 29.81 x 23.14 mm - 36.09 x 23.14 |
| Fov detector long side vertical @ 1/2.0″ (mm) | 025.95 x 34.59 |
| Fov detector long side vertical @ 1/2.5″ | 23.14 x 30.81 - 23.14 x 31.84 - 23.14 x 35.40 - 23.14 x 42.86 |
| Fov detector long side vertical @ 1/2″ | 25.95 x 34.59 25.95 x 35.75 25.95 x 39.75 25.95 x 48.12 |
| Fov detector long side vertical @ 1/3.0″ | 19.46 x 25.95 mm - 19.46 x 26.82 mm - 19.46 x 29.81 mm - 19.46 x 36.09 mm |
| Fov detector long side vertical @ 1/3″ | 19.46 x 25.95 mm 19.46 x 26.82 mm 19.46 x 29.81 mm 19.46 x 36.09 mm |
| Fov detector long side vertical @ 2/3″ | 38.32 x 45.95 mm - 38.32 x 47.49 mm - 38.32 x 52.80 mm - 38.32 x 63.91 mm |
| Front diameter | 75 mm |
| Horizontal magnification | 0.185 0.185 0.185 0.185 |
| Lens type | Telecentric |
| Mount tilt | 0 ° 2.8 ° 6.1 ° 10.5 ° |
| Mount tilt maximum | 20 ° |
| Object tilt | 0 ° 15 ° 30 ° 45 ° |
| Operating temperature range | 0 to 40°C |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.10° |
| Telecentricity typical | < 0.08° |
| Vertical magnification | 0.185 0.179 0.161 0.133 |
| Working ƒ/n | f/8 |
| Weight | 795 Grams |
