Telecentric lenses
0.11× telecentric lens, 2/3", C-mount (LS-TCL-0389)
Model LS-TCL-0389
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 226.7 mm; depth of field 34.2 mm.
Specifications
| Model | LS-TCL-0389 |
|---|---|
| Magnification | 0.11× |
| Working distance | 226.7 mm |
| Sensor format | 2/3" |
| Mount | C-Mount |
| Depth of field | 34.2 mm |
| Dimensions approximate | 578 x 193 x 162 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.02 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 64.82 x 48.45 mm |
| Fov @ 1/2.0″ | 58.18 x 43.64 mm |
| Fov @ 1/2.5″ | 51.82 x 38.91 mm |
| Fov @ 1/2″ | 58.18 x 43.64 mm |
| Fov @ 1/3.0″ | 43.64 x 32.73 mm |
| Fov @ 2/3″ | 77.27 x 64.45 mm |
| Image circle | 11.1 mm |
| Image size dimensions | 9.6 x 9.6 mm |
| Installation location | Indoor Use Only |
| LED current | 350 mA |
| LED voltage | 2.8 Volts |
| Lens type | Telecentric |
| Light color | Green |
| Operating relative humidity (%) | 20-85 Non Condensing |
| Operating temperature range | 0 to 40°C |
| Power consumption maximum | 2.5 Watts |
| Pulse current maximum | 2000 mA |
| Resolution (pixel size) | 46 μm |
| Storage temperature range | 0 to 50°C |
| Supply voltage | 12 - 24 Volts |
| Telecentricity maximum | 0.08° |
| Telecentricity typical | < 0.04° |
| Wavelength | 525 nm |
| Working ƒ/n | f/8 |
| Weight | 11373 Grams |
