Home / Lenses / Telecentric lenses / 0.184× telecentric lens, 2/3", C-Mount

0.184× telecentric lens, 2/3", C-Mount (LS-TCL-0386)

Rendered illustration: the actual product may differ in appearance.

Telecentric lenses

0.184× telecentric lens, 2/3", C-Mount (LS-TCL-0386)

Model LS-TCL-0386

0.184× telecentric lens, 2/3", C-Mount. Working distance 132.9 mm. Depth of field 12.2 mm.

Datasheet (PDF) - LS-TCL-0386 3D model (STEP) - LS-TCL-0386

Specifications

Model	LS-TCL-0386
Depth Of Field	12.2 mm
Distortion Maximum (%)	< 0.1
Distortion Typical (%)	< 0.05
Filter Thread	No Filter Threads
FoV @ 1/1.8″	38.75 x 28.97 mm
FoV @ 1/2.0″	34.78 x 26.09 mm
FoV @ 1/2.5″	30.98 x 23.26 mm
FoV @ 1/3.0″	26.09 x 19.57 mm
FoV @ 2/3″	46.20 x 38.53 mm
Image Circle Diameter	11 mm
Image Size Dimensions	9.6 x 9.6 mm
Imager Format	2/3"
Lens Type	Telecentric
Magnification	0.184×
Mount	C-Mount
Resolution (Pixel Size)	28 μm
Telecentricity Maximum	0.10°
Telecentricity Typical	< 0.08°
Working Distance	132.9 mm
Working ƒ/N	f/8
