Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.259× telecentric lens, 1.1", C-mount (LS-TCL-0381)
Model LS-TCL-0381
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 157.8 mm; depth of field 6.2 mm.
Specifications
| Model | LS-TCL-0381 |
|---|---|
| Magnification | 0.259× |
| Working distance | 157.8 mm |
| Sensor format | 1.1" |
| Mount | C-Mount |
| Depth of field | 6.2 mm |
| Dimensions approximate | 162.3 x 110 x 94 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.08 |
| Filter thread | No Filter Threads |
| Fov @ 1.1″ | 54.67 x 40.04 mm |
| Fov @ 1/2.0″ | 43.82 x 27.53 mm |
| Fov @ 1/2″ | 43.82 x 27.53 mm |
| Fov @ 1″ | 54.79 x 29 mm |
| Image circle | 17.6 mm |
| Image size dimensions | 15.29 x 15.29 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 20 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.10° |
| Telecentricity typical | < 0.08° |
| Working ƒ/n | f/8 |
| Weight | 1605 Grams |
